- Part Number RT9045GSP
- Manufacturer RICHTEK
- Pin Count 9
- Part Category Integrated Circuit
- Package Category Small Outline Packages
- Footprint Name Small Outline Packages - RT9045GSP
- Released Date Sep 10, 2020
- Last Modified Date Jun 22, 2023 10:55 AM UTC
- Pinout / Pin List Click Here (Member Only)
RT9045GSP Details
-
Manufacturer Part Number:
RT9045GSP
-
Rohs Code:
Yes
-
Part Life Cycle Code:
Active
-
Part Package Code:
PSOP-8
-
Package Description:
SOP-8
-
Manufacturer Package Code:
PSOP-8
-
ECCN Code:
EAR99
-
HTS Code:
8542.39.00.60
-
Manufacturer:
Richtek Technology Corp
-
JESD-30 Code:
R-PDSO-G8
-
Length:
4.9 mm
RT9045GSP Frequently Asked Questions (FAQs)
-
A 4-layer PCB with a solid ground plane and a separate power plane is recommended. Keep the input and output capacitors close to the IC, and use short and wide traces for the power lines.
-
To ensure stability, use a minimum output capacitance of 10uF, and ensure that the output capacitor's ESR is less than 1 ohm. Also, avoid using ceramic capacitors with high ESR values.
-
The RT9045GSP can handle a maximum input voltage of 18V, but it's recommended to keep the input voltage below 15V for optimal performance and reliability.
-
The output voltage of the RT9045GSP can be calculated using the formula: Vout = 0.8V x (1 + R1/R2), where R1 and R2 are the resistors in the feedback network.
-
The RT9045GSP can deliver a maximum output current of 2A, but it's recommended to keep the output current below 1.5A for optimal performance and reliability.
