RURP1560 - onsemi

RURP1560 Details

• Manufacturer Part Number:

  RURP1560

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  TO-220-2

• Package Description:

  ROHS COMPLIANT, TO-220AC, 2 PIN

• Manufacturer Package Code:

  340BA

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Factory Lead Time:

  4 Weeks

• Manufacturer:

  onsemi

• YTEOL:

  0

• Application:

  ULTRA FAST SOFT RECOVERY

• Breakdown Voltage-Min:

  600 V

• Case Connection:

  CATHODE

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  1.2 V

• JEDEC-95 Code:

  TO-220AC

• JESD-30 Code:

  R-PSFM-T2

• JESD-609 Code:

  e3

• Non-rep Pk Forward Current-Max:

  200 A

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  15 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Power Dissipation-Max:

  100 W

• Qualification Status:

  Not Qualified

• Rep Pk Reverse Voltage-Max:

  600 V

• Reverse Current-Max:

  100 µA

• Reverse Recovery Time-Max:

  0.06 µs

• Reverse Test Voltage:

  600 V

• Surface Mount:

  NO

• Technology:

  AVALANCHE

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED
