RV-3029-C3 - Micro Crystal AG

RV-3029-C3 Details

• Manufacturer Part Number:

  RV-3029-C3

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Package Description:

  SON-10

• Country Of Origin:

  Switzerland

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Micro Crystal AG

• YTEOL:

  3

• Additional Feature:

  IT ALSO HAS WIDE INTERFACE OPERATING VOLTAGE: 1.4-5.5 V

• Bus Compatibility:

  I2C

• Clock Frequency-Max:

  0.032 MHz

• Information Access Method:

  SERIAL(I2C)

• Interrupt Capability:

  Y

• JESD-30 Code:

  R-CDSO-N10

• JESD-609 Code:

  e4

• Length:

  3.7 mm

• Number of Terminals:

  10

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  VSON

• Package Equivalence Code:

  SOLCC10,.1,32

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, VERY THIN PROFILE

• Peak Reflow Temperature (Cel):

  260

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  0.9 mm

• Supply Current-Max:

  0.06 mA

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  1.4 V

• Supply Voltage-Nom:

  3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  AUTOMOTIVE

• Terminal Finish:

  Gold Flash (Au)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.8 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  40

• Volatile:

  NO

• Width:

  2.5 mm

• uPs/uCs/Peripheral ICs Type:

  TIMER, REAL TIME CLOCK
