RV-3049-C2 - Micro Crystal AG

RV-3049-C2 Details

• Manufacturer Part Number:

  RV-3049-C2

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  SMD-10

• Country Of Origin:

  Switzerland

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Micro Crystal AG

• YTEOL:

  0

• Additional Feature:

  IT IS ALSO AVAILABLE AT -40 TO 85 DEG CEN AND 1.8V TO 5.5V SUPPLY VOLTAGE

• Bus Compatibility:

  SPI

• Clock Frequency-Max:

  0.032 MHz

• Information Access Method:

  SERIAL(SPI), SERIAL, 4-WIRE

• Interrupt Capability:

  Y

• JESD-30 Code:

  R-PDSO-N10

• JESD-609 Code:

  e4

• Length:

  5 mm

• Number of Terminals:

  10

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HSON

• Package Equivalence Code:

  SOLCC10,.12,40

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG

• Peak Reflow Temperature (Cel):

  260

• Seated Height-Max:

  1.2 mm

• Supply Current-Max:

  0.075 mA

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  1.3 V

• Supply Voltage-Nom:

  3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  AUTOMOTIVE

• Terminal Finish:

  Gold (Au)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  1 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  40

• Volatile:

  NO

• Width:

  3.2 mm

• uPs/uCs/Peripheral ICs Type:

  TIMER, REAL TIME CLOCK
