RVPX-J16MM1 - Amphenol

RVPX-J16MM1 Details

• Manufacturer Part Number:

  RVPX-J16MM1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Manufacturer:

  Amphenol Corporation

• YTEOL:

  7

• Board Mounting Option:

  PEG

• Body Breadth:

  0.732 inch

• Body Depth:

  0.413 inch

• Body Length:

  1.158 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  BOARD CONNECTOR

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Finish Termination:

  TIN OVER NICKEL

• Contact Gender:

  FEMALE

• Contact Material:

  NOT SPECIFIED

• Contact Pattern:

  RECTANGULAR

• Filter Feature:

  NO

• Insulator Material:

  GLASS FILLED LIQUID CRYSTAL POLYMER

• JESD-609 Code:

  e3

• Mating Contact Pitch:

  0.071 inch

• Mating Contact Row Spacing:

  0.071 inch

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  9

• Number of Rows Loaded:

  9

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -55 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  RECTANGULAR

• PCB Contact Row Spacing:

  1.8034 mm

• Plating Thickness:

  50u inch

• Rated Current (Signal):

  1.5 A

• Reference Standard:

  UL

• Terminal Length:

  0.094 inch

• Terminal Pitch:

  1.8034 mm

• Termination Type:

  PRESS FIT

• Total Number of Contacts:

  144
