RZ03-1A4-D005 - TE Connectivity

RZ03-1A4-D005 Details

• Manufacturer Part Number:

  RZ03-1A4-D005

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  TE Connectivity

• YTEOL:

  5.6

• Body Breadth:

  12.7 mm

• Body Height:

  15.7 mm

• Body Length or Diameter:

  29 mm

• Coil Power:

  420 mW

• Coil Resistance:

  60 Ω

• Coil Voltage(DC)-Max:

  5 V

• Contact Current(AC)-Max:

  16 A

• Contact Current(DC)-Max:

  16 A

• Contact Voltage(AC)-Max:

  400 V

• Dielectric Strength Between Coil and Contacts:

  5000 Vrms

• Dielectric Strength Between Open Contacts:

  1000 Vrms

• End Contact Material:

  SILVER NICKEL

• Mounting Feature:

  PANEL MOUNT

• Operating Temperature-Max:

  85 °C

• Packing Method:

  BOX; TUBE

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM A

• Relay Type:

  POWER/SIGNAL RELAY

• Surface Mount:

  NO

• Termination Type:

  SOLDER/QUICK CONNECT

• Weight:

  10 g
