S-812C30AMC-C2KT2G - ABLIC Inc.

S-812C30AMC-C2KT2G Details

• Manufacturer Part Number:

  S-812C30AMC-C2KT2G

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  SOT-23

• Package Description:

  SOT-23, 5 PIN

• Pin Count:

  5

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  16 Weeks

• Manufacturer:

  ABLIC Inc.

• YTEOL:

  6

• Dropout Voltage1-Max:

  0.41 V

• Dropout Voltage1-Nom:

  0.23 V

• Input Voltage-Max:

  16 V

• Input Voltage-Min:

  4 V

• JESD-30 Code:

  R-PDSO-G5

• Length:

  2.9 mm

• Load Regulation-Max(%):

  0.045%

• Number of Functions:

  1

• Number of Terminals:

  5

• Output Current1-Max:

  0.05 A

• Output Voltage1-Max:

  3.06 V

• Output Voltage1-Min:

  2.94 V

• Output Voltage1-Nom:

  3 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  LSSOP

• Package Equivalence Code:

  TSOP5,.11,37

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, LOW PROFILE, SHRINK PITCH

• Qualification Status:

  Not Qualified

• Regulator Type:

  FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  1.3 mm

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.95 mm

• Terminal Position:

  DUAL

• Voltage Tolerance-Max:

  2%

• Width:

  1.6 mm
