S22B-AIT2G-2FS - JTS

S22B-AIT2G-2FS Details

• Manufacturer Part Number:

  S22B-AIT2G-2FS

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  JST Manufacturing

• YTEOL:

  7.74

• Additional Feature:

  LOW PROFILE, SIDE ENTRY

• Body Breadth:

  0.665 inch

• Body Depth:

  0.882 inch

• Body Length:

  1.599 inch

• Connector Type:

  COMBINATION LINE CONNECTOR

• Contact Finish Mating:

  GOLD

• Contact Finish Termination:

  Tin (Sn)

• Contact Gender:

  MALE

• Contact Material:

  BRASS

• Contact Style:

  SQ PIN-SKT

• DIN Conformance:

  NO

• Empty Shell:

  NO

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insulator Material:

  GLASS FILLED POLYBUTYLENE TEREPHTHALATE

• JESD-609 Code:

  e3

• MIL Conformance:

  NO

• Mating Information:

  MULTIPLE MATING PARTS AVAILABLE

• Mixed Contacts:

  NO

• Mounting Type:

  BOARD

• Number of Rows Loaded:

  2

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• Rated Current (Signal):

  5 A

• Termination Type:

  SOLDER

• Total Number of Contacts:

  22
