S24B12C200BL - VICOR

S24B12C200BL Details

• Manufacturer Part Number:

  S24B12C200BL

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-9

• ECCN Code:

  EAR99

• Manufacturer:

  Vicor Corporation

• YTEOL:

  6

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Control Mode:

  VOLTAGE-MODE

• Input Voltage-Max:

  36 V

• Input Voltage-Min:

  18 V

• Input Voltage-Nom:

  24 V

• JESD-30 Code:

  R-XDFM-P9

• Length:

  55.88 mm

• Line Regulation-Max:

  0.2%

• Load Regulation-Max:

  0.2%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -20 °C

• Output Voltage-Max:

  13.2 V

• Output Voltage-Min:

  1.2 V

• Output Voltage-Nom:

  12 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DFM

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  OTHER

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  200 W

• Trim/Adjustable Output:

  YES

• Width:

  57.91 mm
