SA5521D - NXP

SA5521D Details

• Manufacturer Part Number:

  SA5521D

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SOIC

• Package Description:

  0.300 INCH, PLASTIC, SOL-16

• Pin Count:

  16

• HTS Code:

  8542.39.00.50

• Manufacturer:

  NXP Semiconductors

• YTEOL:

  0

• Additional Feature:

  IT CAN ALSO OPERATE FROM A +/-2.5V TO +/-10V SUPPLY

• Analog Input Voltage-Max:

  10 V

• Converter Type:

  SIGNAL CONDITIONER

• JESD-30 Code:

  R-PDSO-G16

• Length:

  10.3 mm

• Number of Terminals:

  16

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SOP

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  2.65 mm

• Supply Voltage-Max:

  20 V

• Supply Voltage-Min:

  5 V

• Surface Mount:

  YES

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Width:

  7.5 mm
