A 4-layer PCB with a solid ground plane and a separate power plane is recommended. Keep the input and output traces short and away from each other to minimize noise coupling.
Ensure the VCC pin is connected to a stable 5V power supply, and the VEE pin is connected to a stable -5V power supply. The bias voltage (VBIAS) should be set to 2.5V, and the input voltage (VIN) should be AC-coupled to the SA571DG.
The maximum input signal amplitude that the SA571DG can handle is ±1.4V peak-to-peak. Exceeding this limit may cause distortion and affect the device's performance.
Use a low-pass filter at the input, keep the input and output traces short and away from each other, and use a shielded enclosure to minimize electromagnetic interference (EMI).
The recommended operating temperature range for the SA571DG is -40°C to +85°C. Operating the device outside this range may affect its performance and reliability.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
SA571DG Overview
Use the download button to access the SA571DG schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like SA571,
or try a keyword search, such as Analog Computational Functions
