SAP15P - SANKEN ELECTRIC CO.

SAP15P Details

• Manufacturer Part Number:

  SAP15P

• Part Life Cycle Code:

  Obsolete

• Reach Compliance Code:

  Unknown

• ECCN Code:

  EAR99

• Manufacturer:

  Sanken Electric Co Ltd

• YTEOL:

  0

• Collector Current-Max (IC):

  15 A

• Collector-Emitter Voltage-Max:

  160 V

• Configuration:

  DARLINGTON WITH BUILT-IN DIODE AND RESISTOR

• DC Current Gain-Min (hFE):

  5000

• JESD-30 Code:

  R-PSFM-T5

• Number of Elements:

  1

• Number of Terminals:

  5

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Polarity/Channel Type:

  PNP

• Qualification Status:

  Not Qualified

• Surface Mount:

  NO

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE

• Transistor Application:

  AMPLIFIER

• Transistor Element Material:

  SILICON
