SB3231-E1 - onsemi

Description: Obsolete - Preconfigured DSP System for Hearing Aids, with up to 4 WDRC channels

Download SB3231-E1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
SB3231-E1 - onsemi PCB footprint - Other - Other - SIP25, 5.59x3.18 CASE 127DN ISSUE O
click to zoom
3D Models
SB3231-E1 - onsemi  - 3D model - Other - SIP25, 5.59x3.18 CASE 127DN ISSUE O
click to zoom

SB3231-E1 Details

  • Manufacturer Part Number:

    SB3231-E1

  • Brand Name:

    onsemi

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    SIP-25

  • Package Description:

    PAD-25

  • Manufacturer Package Code:

    127DN

  • HTS Code:

    8542.31.00.30

  • Manufacturer:

    onsemi

  • YTEOL:

    0

  • Additional Feature:

    SEATED HGT-NOM

  • JESD-30 Code:

    R-XXMA-N25

  • Length:

    5.59 mm

  • Number of Terminals:

    25

  • Operating Temperature-Max:

    40 °C

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    XMA

  • Package Shape:

    RECTANGULAR

  • Package Style:

    MICROELECTRONIC ASSEMBLY

  • Seated Height-Max:

    1.525 mm

  • Supply Voltage-Nom:

    1.25 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    COMMERCIAL

  • Terminal Form:

    NO LEAD

  • Terminal Position:

    UNSPECIFIED

  • Width:

    3.81 mm

  • uPs/uCs/Peripheral ICs Type:

    MICROPROCESSOR CIRCUIT
