The maximum operating temperature range for the SB82371SB is 0°C to 70°C (32°F to 158°F).
The chip select signals for the SB82371SB can be configured using the CS[3:0] pins, which can be programmed to select one of the eight possible chip select configurations.
The RSTOUT# signal on the SB82371SB is an active-low reset output signal that indicates when the chip has completed its power-on reset sequence.
Yes, the SB82371SB is designed to operate with a 3.3V power supply, and it is 3.3V tolerant on all input and output pins.
The SB82371SB generates interrupt signals on the INTR and SMI# pins, which can be handled by connecting them to an interrupt controller or a processor's interrupt input.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
SB82371SB Overview
Use the download button to access the SB82371SB schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like SB823,
or try a keyword search, such as Bus Controllers
