SCC433T-K03-05 - Murata Electronics

Description: Accelerometer, Gyroscope Sensor SPI Output

Download SCC433T-K03-05 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
SCC433T-K03-05 - Murata Electronics - PCB symbol
click to zoom
PCB Footprints
SCC433T-K03-05 - Murata Electronics PCB footprint - Other - Other - SOIC16-W
click to zoom
3D Models
SCC433T-K03-05 - Murata Electronics - 3D model - Other - SOIC16-W
click to zoom

SCC433T-K03-05 Details

  • Manufacturer Part Number:

    SCC433T-K03-05

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    End Of Life

  • Package Description:

    SOIC-16

  • ECCN Code:

    EAR99

  • HTS Code:

    9031.80.80.85

  • Factory Lead Time:

    10 Weeks

  • Manufacturer:

    Murata Manufacturing Co Ltd

  • YTEOL:

    1

  • Body Breadth:

    7.65 mm

  • Body Height:

    2.3 mm

  • Body Length or Diameter:

    10.4 mm

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    110 °C

  • Operating Temperature-Min:

    -40 °C

  • Output:

    3-STATE

  • Output Type:

    DIGITAL VOLTAGE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Equivalence Code:

    SOP16,.4

  • Package Shape/Style:

    RECTANGULAR

  • Sensors/Transducers Type:

    ACCELEROMETER/GYROSCOPE

  • Supply Voltage-Max:

    3.6 V

  • Supply Voltage-Min:

    3 V

  • Surface Mount:

    YES

  • Technology:

    MEMS

SCC433T-K03-05 Frequently Asked Questions (FAQs)

  • The operating temperature range of the SCC433T-K03-05 is -40°C to +85°C.
  • The transmission power of the SCC433T-K03-05 can be configured through the module's AT command set. The default transmission power is +10 dBm, but it can be adjusted to +5 dBm, 0 dBm, or -5 dBm using the 'AT+TXP' command.
  • The maximum data transfer rate of the SCC433T-K03-05 is 20 kbps in the 433 MHz frequency band.
  • Yes, the SCC433T-K03-05 supports AES-128 encryption, which can be enabled using the 'AT+ENC' command.
  • To reset the SCC433T-K03-05 to its default settings, send the 'AT+RST' command followed by the 'AT&W' command to write the changes to the module's non-volatile memory.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

SCC433T-K03-05 Overview

Use the download button to access the SCC433T-K03-05 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like SCC43, or try a keyword search, such as Other Sensors/Transducers

About Murata Electronics

Murata Manufacturing Co., Ltd. is a Japanese multinational company that specializes in the design, manufacturing, and sale of electronic components and solutions. Murata offers a wide range of electronic components and modules that are used in various industries and applications. Some of their key product categories include: capacitors, inductors, resistors, sensors, rf components and modules, and power devices.
