SCG-3-162+ - Mini-Circuits

Description: Signal Conditioning PWR SPLTR CMBD / SURF MT RoHS

Download SCG-3-162+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
SCG-3-162+ - Mini-Circuits PCB footprint - Other - Other - SCG-3-162+-1
click to zoom
3D Models
SCG-3-162+ - Mini-Circuits  - 3D model - Other - SCG-3-162+-1
click to zoom

SCG-3-162+ Details

  • Manufacturer Part Number:

    SCG-3-162+

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • Manufacturer:

    Mini-Circuits

  • YTEOL:

    6.85

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Input Power-Max (CW):

    33.01 dBm

  • Insertion Loss-Max:

    1.8 dB

  • Isolation-Min:

    11.5 dB

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    6

  • Operating Frequency-Max:

    1600 MHz

  • Operating Frequency-Min:

    900 MHz

  • Operating Temperature-Max:

    100 °C

  • Operating Temperature-Min:

    -55 °C

  • Package Body Material:

    CERAMIC, METAL-SEALED COFIRED

  • Package Equivalence Code:

    SOLCC6,.05,25

  • RF/Microwave Device Type:

    SPLITTER AND COMBINER

  • Surface Mount:

    YES

  • VSWR-Max:

    1.22
