SCG-3-752+ - Mini-Circuits

SCG-3-752+ Details

• Manufacturer Part Number:

  SCG-3-752+

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Manufacturer:

  Mini-Circuits

• YTEOL:

  7

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Input Power-Max (CW):

  33.01 dBm

• Insertion Loss-Max:

  2.1 dB

• Isolation-Min:

  11 dB

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Frequency-Max:

  7500 MHz

• Operating Frequency-Min:

  4500 MHz

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Equivalence Code:

  SOLCC6,.05,25

• RF/Microwave Device Type:

  SPLITTER AND COMBINER

• Screening Level:

  5G; WIFI6

• Surface Mount:

  YES

• VSWR-Max:

  1.92
