SCPQ-50+ - Mini-Circuits

SCPQ-50+ Details

• Manufacturer Part Number:

  SCPQ-50+

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  Mini-Circuits

• YTEOL:

  6.59

• Additional Feature:

  HIGH ISOLATION

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Input Power-Max (CW):

  30 dBm

• Insertion Loss-Max:

  0.7 dB

• Isolation-Min:

  20 dB

• JESD-609 Code:

  e3

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  8

• Operating Frequency-Max:

  50 MHz

• Operating Frequency-Min:

  25 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Equivalence Code:

  FL8,.38,200

• RF/Microwave Device Type:

  90 DEGREE HYBRID COUPLER

• Surface Mount:

  YES

• Terminal Finish:

  Tin (Sn) - with Nickel (Ni) barrier

• VSWR-Max:

  1.16
