SD10H0SB - LITTELFUSE

SD10H0SB Details

• Manufacturer Part Number:

  SD10H0SB

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  6

• Actuator Material:

  POLYAMIDE

• Actuator Type:

  SLIDE TYPE

• Additional Feature:

  APPROVAL: UL

• Body Breadth:

  6.68 mm

• Body Height:

  4.31 mm

• Body Length or Diameter:

  26.87 mm

• Center Contact Material:

  BERYLLIUM COPPER

• Center Contact Plating:

  GOLD

• Contact Current(DC)-Max:

  0.1 A

• Contact (DC) Max Rating R Load:

  0.1A@25VDC

• Contact Function:

  OFF-ON

• Contact Resistance:

  0.05 mΩ

• Contact Voltage(DC)-Max:

  25 V

• Dielectric Withstand Volts:

  500VRMS V

• Electrical Life:

  2000 Cycle(s)

• End Contact Material:

  BERYLLIUM COPPER

• End Contact Plating:

  GOLD

• Housing Material:

  POLYPHTHALAMIDE

• Insulation Resistance:

  1000000000 Ω

• Insulator Material:

  POLYPHTHALAMIDE

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Number of Switch Sections:

  10

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  TUBE

• Sealing:

  TOP TAPE SEALED

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SPST

• Switch Type:

  SLIDE DIP SWITCH

• Terminal Finish:

  Bright Tin (Sn)

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER
