The recommended mating sequence is to mate the contacts first, followed by the shields. This ensures proper electrical connection and minimizes the risk of damage or bent pins.
Yes, the SDL107-G-10 connector is designed to withstand high-vibration environments. Samtec's SDL series connectors have undergone rigorous testing, including vibration testing per IEC 60512-2, and have proven to be reliable in such conditions.
The maximum operating temperature for the SDL107-G-10 connector is 125°C (257°F). However, it's essential to note that the connector's performance and lifespan may be affected by prolonged exposure to high temperatures.
Yes, the SDL107-G-10 connector is RoHS (Restriction of Hazardous Substances) and REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) compliant, meeting the requirements for environmental sustainability and safety.
The recommended torque for the SDL107-G-10 connector's screws is 0.5-1.5 N·m (0.37-1.06 lbf·in·lb). It's essential to follow this torque specification to prevent damage to the connector or the PCB.
