SEAF8-30-05.0-STL-06-1 - SAMTEC

SEAF8-30-05.0-STL-06-1 Details

• Manufacturer Part Number:

  SEAF8-30-05.0-STL-06-1

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Malaysia, USA

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Factory Lead Time:

  9 Weeks, 5 Days

• Manufacturer:

  Samtec Inc

• YTEOL:

  9

• Additional Feature:

  SEARAY

• Board Mounting Option:

  PEG

• Body Breadth:

  0.307 inch

• Body Depth:

  0.18 inch

• Body Length:

  1.175 inch

• Body/Shell Style:

  SOCKET

• Connector Type:

  BOARD STACKING CONNECTOR

• Contact Finish Termination:

  Matte Tin/Lead (Sn/Pb)

• Contact Gender:

  FEMALE

• Contact Pattern:

  RECTANGULAR

• Contact Resistance:

  15 mΩ

• Contact Style:

  CENTRONIC

• Dielectric Withstanding Voltage:

  660VAC V

• Durability:

  1000 Cycles

• Filter Feature:

  NO

• Insulation Resistance:

  15000000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  LIQUID CRYSTAL POLYMER

• JESD-609 Code:

  e0

• Mating Contact Pitch:

  0.031 inch

• Mating Contact Row Spacing:

  0.02 inch

• Mating Information:

  MULTIPLE MATING PARTS AVAILABLE

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  6

• Number of Rows Loaded:

  6

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  RECTANGULAR

• PCB Contact Row Spacing:

  0.8 mm

• Plating Thickness:

  30u inch

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  1.3 A

• Reference Standard:

  UL

• Terminal Pitch:

  0.8 mm

• Termination Type:

  SURFACE MOUNT

• Total Number of Contacts:

  180
