SED1335FOB - S-MOS Systems

SED1335FOB Details

• Manufacturer Part Number:

  SED1335FOB

• Part Life Cycle Code:

  Obsolete

• Package Description:

  QFP6-60

• HTS Code:

  8542.31.00.30

• Manufacturer:

  S-MOS Systems

• YTEOL:

  0

• Address Bus Width:

  1

• Bus Compatibility:

  80 FAMILY; 68 FAMILY

• Clock Frequency-Max:

  10 MHz

• External Data Bus Width:

  8

• JESD-30 Code:

  S-PQFP-G60

• Moisture Sensitivity Level:

  1

• Number of Terminals:

  60

• Operating Temperature-Max:

  75 °C

• Operating Temperature-Min:

  -20 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  QFP

• Package Equivalence Code:

  QFP60,.7SQ,32

• Package Shape:

  SQUARE

• Package Style:

  FLATPACK

• Qualification Status:

  Not Qualified

• Supply Current-Max:

  15 mA

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  2.7 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL EXTENDED

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.8 mm

• Terminal Position:

  QUAD

• uPs/uCs/Peripheral ICs Type:

  DISPLAY CONTROLLER, DOT MATRIX LCD DISPLAY
