SER2LGYRDGNAU0A - LITTELFUSE

SER2LGYRDGNAU0A Details

• Manufacturer Part Number:

  SER2LGYRDGNAU0A

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.40

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  7

• Actuator Travel:

  2.9972 mm

• Actuator Type:

  KEYPAD

• Center Contact Plating:

  GOLD

• Contact Current(DC)-Max:

  0.01 A

• Contact (DC) Max Rating R Load:

  0.01A@24VDC

• Contact Resistance:

  0.1 mΩ

• Contact Voltage(DC)-Max:

  24 V

• Dielectric Withstand Volts:

  500VAC V

• End Contact Plating:

  GOLD

• Illumination:

  LED

• Insulation Resistance:

  1000000000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPDT

• Switch Type:

  KEYPAD SWITCH

• Terminal Length:

  0.177 inch

• Termination Type:

  SOLDER
