SETLBKRD7.62AUOA - LITTELFUSE

SETLBKRD7.62AUOA Details

• Manufacturer Part Number:

  SETLBKRD7.62AUOA

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.40

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  7

• Actuator Color:

  BLACK

• Actuator Travel:

  3 mm

• Actuator Type:

  WIDE BUTTON TYPE

• Body Breadth:

  17.1 mm

• Body Length or Diameter:

  17.3 mm

• Center Contact Material:

  GOLD

• Circuit Configuration:

  1X1

• Contact Bounce Time-Max:

  2.5 ms

• Contact Current(DC)-Max:

  0.01 A

• Contact (DC) Max Power Rating R Load:

  0.24VA@24VDC

• Contact (DC) Max Rating R Load:

  .01A@24VDC

• Contact Resistance:

  0.05 mΩ

• Contact Timing:

  BREAK-BEFORE-MAKE

• Contact Voltage(DC)-Max:

  24 V

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  5000000 Cycle(s)

• End Contact Material:

  GOLD

• Illumination:

  RED LED

• Insulation Resistance:

  10000000000 Ω

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Switches:

  1

• Operating Force-Max:

  2 N

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• PCB Hole Count:

  10

• Solderability:

  HAND/WAVE

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPDT

• Switch Type:

  KEYPAD SWITCH

• Terminal Finish:

  Gold (Au)

• Termination Type:

  SOLDER
