SFS3-L-DC48V - Panasonic

SFS3-L-DC48V Details

• Manufacturer Part Number:

  SFS3-L-DC48V

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  Panasonic Electronic Components

• Body Breadth:

  13 mm

• Body Height:

  24 mm

• Body Length or Diameter:

  50 mm

• Coil Current(DC)-Max:

  0.008 A

• Coil Operate Voltage(DC):

  36 V

• Coil Power:

  360 mW

• Coil Release Voltage(DC):

  4.8 V

• Coil Resistance:

  6400 Ω

• Coil Voltage(DC)-Max:

  48 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  6A@250VAC

• Contact Current(AC)-Max:

  6 A

• Contact Current(DC)-Max:

  6 A

• Contact (DC) Max Rating R Load:

  6A@30VDC

• Contact Voltage(AC)-Max:

  250 V

• Contact Voltage(DC)-Max:

  30 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• Mounting Feature:

  THROUGH HOLE-STRAIGHT MOUNT

• Operate Time:

  20 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX

• Physical Dimension:

  50mm x 13mm x 24mm

• Reference Standard:

  TUV; UL

• Relay Action:

  MOMENTARY

• Relay Function:

  4PST

• Relay Type:

  SAFETY RELAY

• Release Time:

  20 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER
