SH8K1TB - ROHM Semiconductor

SH8K1TB Details

• Manufacturer Part Number:

  SH8K1TB

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SOT

• Package Description:

  SMALL OUTLINE, R-PDSO-G8

• Pin Count:

  8

• Reach Compliance Code:

  Unknown

• ECCN Code:

  EAR99

• Manufacturer:

  ROHM Semiconductor

• YTEOL:

  0

• Additional Feature:

  ESD PROTECTED

• Configuration:

  SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  30 V

• Drain Current-Max (ID):

  5 A

• Drain-source On Resistance-Max:

  0.082 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• JESD-30 Code:

  R-PDSO-G8

• Number of Elements:

  1

• Number of Terminals:

  8

• Operating Mode:

  ENHANCEMENT MODE

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Polarity/Channel Type:

  N-CHANNEL

• Pulsed Drain Current-Max (IDM):

  20 A

• Qualification Status:

  Not Qualified

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
