SI5332D-D-AM3R - Skyworks

SI5332D-D-AM3R Details

• Manufacturer Part Number:

  SI5332D-D-AM3R

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  QFN-48

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Skyworks Solutions Inc

• YTEOL:

  7.75

• Additional Feature:

  IT ALSO REQUIRES 2.5V AND 3.3 V NOMINAL SUPPLY VOLTAGE

• JESD-30 Code:

  S-XQCC-N48

• Length:

  7 mm

• Number of Terminals:

  48

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Output Clock Frequency-Max:

  200 MHz

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC48,.27SQ,20

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Primary Clock/Crystal Frequency-Nom:

  250 MHz

• Screening Level:

  AEC-Q100; AEC-Q006

• Seated Height-Max:

  0.9 mm

• Supply Current-Max:

  70 mA

• Supply Voltage-Max:

  3.46 V

• Supply Voltage-Min:

  1.71 V

• Supply Voltage-Nom:

  1.8 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  7 mm

• uPs/uCs/Peripheral ICs Type:

  CLOCK GENERATOR, PROGRAMMABLE
