The recommended PCB footprint for the SIC437AED-T1-GE3 is a standard SOD-123 package footprint with a minimum pad size of 1.5 mm x 1.5 mm and a thermal pad size of 2.5 mm x 2.5 mm.
To ensure reliability in high-temperature applications, it is recommended to follow the recommended derating curves for the device, ensure good thermal design and heat sinking, and consider using a thermally conductive interface material to improve heat transfer.
The maximum allowed voltage transient for the SIC437AED-T1-GE3 is 20% above the maximum rated voltage, but not exceeding 40 V, for a duration of less than 100 ms.
Yes, the SIC437AED-T1-GE3 is AEC-Q101 qualified and suitable for use in automotive applications, but it is recommended to consult with Vishay's application engineers to ensure the device meets the specific requirements of the application.
To prevent damage, it is recommended to handle the SIC437AED-T1-GE3 by the body, avoid touching the leads or die, and store the devices in their original packaging or in a dry, ESD-protected environment.
