SIC474ED-T1-GE3 - Vishay

Description: Switching Voltage Regulators 4.5-55V 3A microBUCK 100kHz-2MHz

Download SIC474ED-T1-GE3 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
SIC474ED-T1-GE3 - Vishay - PCB symbol
click to zoom
PCB Footprints
SIC474ED-T1-GE3 - Vishay PCB footprint - Other - Other - SiC462ED-T1-GE3-2
click to zoom
3D Models
SIC474ED-T1-GE3 - Vishay - 3D model - Other - SiC462ED-T1-GE3-2
click to zoom

SIC474ED-T1-GE3 Details

  • Manufacturer Part Number:

    SIC474ED-T1-GE3

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    MLP-27

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    16 Weeks

  • Date Of Intro:

    2018-09-08

  • Manufacturer:

    Vishay Intertechnologies

  • Analog IC - Other Type:

    SWITCHING REGULATOR

  • Control Mode:

    VOLTAGE-MODE

  • Control Technique:

    PULSE WIDTH MODULATION

  • Input Voltage-Max:

    55 V

  • Input Voltage-Min:

    4.5 V

  • Input Voltage-Nom:

    48 V

  • JESD-30 Code:

    R-XQCC-N27

  • Number of Functions:

    1

  • Number of Terminals:

    27

  • Operating Temperature-Max:

    105 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Current-Max:

    6 A

  • Output Voltage-Max:

    50.6 V

  • Output Voltage-Min:

    0.8 V

  • Package Body Material:

    UNSPECIFIED

  • Package Equivalence Code:

    LCC27(UNSPEC)

  • Package Shape:

    RECTANGULAR

  • Supply Current-Max (Isup):

    3 mA

  • Surface Mount:

    YES

  • Switcher Configuration:

    BUCK

  • Switching Frequency-Max:

    2000 kHz

  • Terminal Form:

    NO LEAD

  • Terminal Position:

    QUAD

SIC474ED-T1-GE3 Frequently Asked Questions (FAQs)

  • The maximum operating temperature range for the SIC474ED-T1-GE3 is -55°C to 175°C.
  • Yes, the SIC474ED-T1-GE3 is designed for high-reliability applications, including aerospace, defense, and industrial systems, due to its robust design and high-quality manufacturing process.
  • The typical lead time for delivery of the SIC474ED-T1-GE3 can vary depending on the quantity and availability, but it's usually around 12-16 weeks. It's recommended to check with authorized distributors or Vishay Intertechnologies directly for the most up-to-date lead time information.
  • Yes, the SIC474ED-T1-GE3 is designed to handle high-voltage applications, with a maximum repetitive peak reverse voltage of 1200 V and a maximum DC blocking voltage of 1000 V.
  • Yes, the SIC474ED-T1-GE3 is RoHS (Restriction of Hazardous Substances) compliant, meaning it meets the European Union's directive on the restriction of certain hazardous substances in electrical and electronic equipment.
