SIRA12S - Pico Electronics

SIRA12S Details

• Manufacturer Part Number:

  SIRA12S

• Pbfree Code:

  No

• Part Life Cycle Code:

  Active

• Part Package Code:

  SFM

• Package Description:

  PACKAGE-12

• Pin Count:

  12

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• Manufacturer:

  Pico Electronics Inc

• YTEOL:

  4

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Efficiency (Main Output):

  78%

• Input Voltage-Max:

  36 V

• Input Voltage-Min:

  18 V

• Input Voltage-Nom:

  27 V

• JESD-30 Code:

  R-XDMA-G12

• JESD-609 Code:

  e0

• Length:

  46.228 mm

• Line Regulation-Max:

  0.5%

• Load Regulation-Max:

  2%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  12

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -25 °C

• Output Current-Max:

  0.667 A

• Output Voltage-Max:

  12.6 V

• Output Voltage-Min:

  12 V

• Output Voltage-Nom:

  12 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,12LEAD,1.7

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  SHORT CIRCUIT

• Qualification Status:

  Not Qualified

• Ripple Voltage (Main Out):

  0.03535 Vrms

• Seated Height-Max:

  13.462 mm

• Surface Mount:

  YES

• Technology:

  HYBRID

• Temperature Grade:

  OTHER

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  GULL WING

• Terminal Pitch:

  7.62 mm

• Terminal Position:

  DUAL

• Total Power Output-Max:

  8 W

• Trim/Adjustable Output:

  YES

• Width:

  38.1 mm
