SIS42212VDC - ELESTA

SIS42212VDC Details

• Manufacturer Part Number:

  SIS42212VDC

• Part Life Cycle Code:

  Contact Manufacturer

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Manufacturer:

  ELESTA GmbH

• Body Breadth:

  16.6 mm

• Body Height:

  16.5 mm

• Body Length or Diameter:

  48 mm

• Coil Current(DC)-Max:

  0.056 A

• Coil Operate Voltage(DC):

  8.4 V

• Coil Power:

  660 mW

• Coil Release Voltage(DC):

  1.2 V

• Coil Resistance:

  215 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil Voltage-Nom:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  6A@250VAC

• Contact Current(AC)-Max:

  6 A

• Contact Current(DC)-Max:

  6 A

• Contact (DC) Max Rating R Load:

  6A@250VDC

• Contact Resistance:

  100 mΩ

• Contact Voltage(AC)-Max:

  250 V

• Contact Voltage(DC)-Max:

  250 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  90000 Cycle(s)

• End Contact Material:

  Silver Copper Nickel Alloy

• End Contact Plating:

  GOLD

• Input Switching Control Type:

  Random

• Insulation Resistance:

  100000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  14

• Operate Time:

  17 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  48mm x 16.6mm x 16.5mm

• Reference Standard:

  CUL; SEV; TUV; UL; VDE

• Relay Action:

  MOMENTARY

• Relay Function:

  6PST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  20 ms

• Sealing:

  RT3

• Surface Mount:

  NO

• Terminal Length:

  0.002799085598171197 inch

• Termination Type:

  SOLDER
