SIT3541AIA2C33320M1.000000 - SiTime

SIT3541AIA2C33320M1.000000 Details

• Manufacturer Part Number:

  SIT3541AIA2C33320M1.000000

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  QFN, 10 PIN

• Country Of Origin:

  Malaysia, Taiwan, Thailand

• Manufacturer:

  SiTime Corporation

• YTEOL:

  8

• Additional Feature:

  ENABLE/DISABLE FUNCTION; COMPLEMENTARY OUTPUT; MIL-PRF-55310; MIL-STD-883F

• Aging:

  1 PPM/FIRST YEAR

• Fall Time-Max:

  0.47 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  50%

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  10

• Operating Frequency-Nom:

  1 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  MEMS DCTCXO, LVDS

• Output Load:

  100 OHM, 2 pF

• Package Equivalence Code:

  LCC10,.12X.2,39

• Physical Dimension:

  5.0mm x 3.2mm x 0.9mm

• Rise Time-Max:

  0.47 ns

• Supply Voltage-Max:

  3.63 V

• Supply Voltage-Min:

  2.97 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %
