SiT5155AECFK-25VT-10.000000 - SiTime

SiT5155AECFK-25VT-10.000000 Details

• Manufacturer Part Number:

  SIT5155AECFK-25VT-10.000000

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CQFN-10

• Country Of Origin:

  Malaysia, Taiwan, Thailand

• Manufacturer:

  SiTime Corporation

• YTEOL:

  8

• Aging:

  1 PPM/YEAR

• Control Voltage-Max:

  2.25 V

• Control Voltage-Min:

  0.25 V

• Frequency Adjustment-Mechanical:

  NO

• Frequency Deviation/Pullability:

  6.25 ppm

• Frequency Stability:

  0.5%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  10

• Operating Frequency-Nom:

  10 MHz

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  CLIPPED SINE

• Output Impedance:

  10000 Ω

• Output Level:

  0.8 V

• Package Body Material:

  CERAMIC

• Package Equivalence Code:

  LCC10,.12X.2,58/52/48

• Physical Dimension:

  5.15mm x 3.35mm x 1.06mm

• Screening Level:

  MIL-STD-883F

• Supply Voltage-Max:

  2.75 V

• Supply Voltage-Min:

  2.25 V

• Supply Voltage-Nom:

  2.5 V

• Surface Mount:

  YES

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier
