SJ-3566BN - Same Sky

SJ-3566BN Details

• Manufacturer Part Number:

  SJ-3566BN

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Same Sky

• YTEOL:

  0

• Additional Feature:

  LOW PROFILE

• Audio Type:

  STEREO

• Body Breadth:

  0.197 inch

• Body Depth:

  0.728 inch

• Body Length:

  0.472 inch

• Body/Shell Style:

  JACK

• Configuration:

  1X1 HORIZONTAL

• Connector Type:

  3.5MM AUDIO

• Contact Gender:

  FEMALE

• Contact Resistance:

  50 mΩ

• Contact Style:

  RND PIN-SKT

• Dielectric Withstanding Voltage:

  500VAC V

• Durability:

  5000 Cycles

• Insertion Force-Max:

  29.4 N

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  POLYAMIDE66

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Poles:

  2

• Number of Ports:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  1 A

• Reference Standard:

  UL

• Terminal Length:

  0.091 inch

• Termination Type:

  SOLDER

• Withdrawl Force-Min:

  2.942 N
