SK-22D07-GNSPA - LITTELFUSE

SK-22D07-GNSPA Details

• Manufacturer Part Number:

  SK-22D07-GNSPA

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Vietnam

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  7

• Actuator Type:

  SLIDE

• Center Contact Material:

  SILVER

• Contact Current(DC)-Max:

  0.3 A

• Contact (DC) Max Rating R Load:

  0.3A@30VDC

• Contact Resistance:

  0.03 mΩ

• Contact Voltage(DC)-Max:

  30 V

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  10000 Cycle(s)

• End Contact Material:

  SILVER

• Insulation Resistance:

  100000000 Ω

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• Number of Positions:

  2

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Surface Mount:

  NO

• Switch Function:

  DPDT

• Switch Type:

  SLIDE SWITCH

• Termination Type:

  SOLDER
