SK70D08 - Semikron

SK70D08 Details

• Manufacturer Part Number:

  SK70D08

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  PLASTIC, CASE T7, SEMITOP 2, 7 PIN

• Pin Count:

  7

• Manufacturer Package Code:

  CASE T7

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Manufacturer:

  SEMIKRON

• YTEOL:

  0

• Case Connection:

  ISOLATED

• Configuration:

  BRIDGE, 6 ELEMENTS

• Diode Element Material:

  SILICON

• Diode Type:

  BRIDGE RECTIFIER DIODE

• Forward Voltage-Max (VF):

  1.25 V

• JESD-30 Code:

  R-PUFM-X7

• JESD-609 Code:

  e2

• Non-rep Pk Forward Current-Max:

  270 A

• Number of Elements:

  6

• Number of Phases:

  3

• Number of Terminals:

  7

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  70 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Qualification Status:

  Not Qualified

• Reference Standard:

  UL RECOGNIZED

• Rep Pk Reverse Voltage-Max:

  800 V

• Surface Mount:

  NO

• Terminal Finish:

  TIN SILVER

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UPPER
