SK70DT16 - Semikron

SK70DT16 Details

• Manufacturer Part Number:

  SK70DT16

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CASE T 15, SEMITOP-28

• Pin Count:

  28

• Manufacturer Package Code:

  CASE T 15

• ECCN Code:

  EAR99

• HTS Code:

  8541.30.00.80

• Manufacturer:

  SEMIKRON

• YTEOL:

  7.07

• Case Connection:

  ISOLATED

• Configuration:

  3 PHASE BRIDGE

• DC Gate Trigger Current-Max:

  100 mA

• JESD-30 Code:

  R-XUFM-X28

• JESD-609 Code:

  e2

• Number of Elements:

  6

• Number of Terminals:

  28

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Qualification Status:

  Not Qualified

• RMS On-state Current-Max:

  68 A

• Reference Standard:

  UL RECOGNIZED

• Repetitive Peak Off-state Voltage:

  1600 V

• Repetitive Peak Reverse Voltage:

  1600 V

• Surface Mount:

  NO

• Terminal Finish:

  TIN SILVER

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UPPER

• Trigger Device Type:

  SCR
