SKHI22AR - Semikron

SKHI22AR Details

• Manufacturer Part Number:

  SKHI22AR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  SEMIKRON

• YTEOL:

  7

• Built-in Protections:

  TRANSIENT; OVER CURRENT; UNDER VOLTAGE

• Interface IC Type:

  HALF BRIDGE BASED IGBT DRIVER

• JESD-30 Code:

  R-XXMA-X

• JESD-609 Code:

  e2

• Number of Functions:

  2

• Number of Terminals:

  18

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current Flow Direction:

  SOURCE AND SINK

• Output Peak Current Limit-Nom:

  20 A

• Package Body Material:

  UNSPECIFIED

• Package Code:

  XMA

• Package Equivalence Code:

  MODULE,18LEAD,1.9

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Qualification Status:

  Not Qualified

• Supply Voltage-Max:

  15.6 V

• Supply Voltage-Min:

  14.4 V

• Supply Voltage-Nom:

  15 V

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Tin/Silver (Sn/Ag)

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UNSPECIFIED

• Turn-off Time:

  1.15 µs

• Turn-on Time:

  1.15 µs
