SLB1470R - Apem

SLB1470R Details

• Manufacturer Part Number:

  SLB1470R

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.50

• Manufacturer:

  APEM Inc

• YTEOL:

  0

• Actuator Length:

  0.197 inch

• Actuator Material:

  THERMOPLASTIC

• Actuator Type:

  SLIDE

• Body Breadth:

  7.5 mm

• Body Height:

  5 mm

• Body Length or Diameter:

  20 mm

• Center Contact Plating:

  SILVER

• Contact (AC) Max Rating R Load:

  .3A@125VAC

• Contact Current(AC)-Max:

  0.3 A

• Contact Current(DC)-Max:

  0.3 A

• Contact (DC) Max Rating R Load:

  .3A@30VDC

• Contact Resistance:

  0.02 mΩ

• Contact Voltage(AC)-Max:

  125 V

• Contact Voltage(DC)-Max:

  30 V

• Dielectric Withstand Volts:

  500VRMS V

• Electrical Life:

  10000 Cycle(s)

• End Contact Plating:

  SILVER

• Housing Material:

  STEEL

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  PHENOLIC

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• Number of Positions:

  4

• Operating Force-Max:

  3.14 N

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -20 °C

• PCB Hole Count:

  8

• Sealing:

  EPOXY TERMINAL SEALED

• Solderability:

  WAVE

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SP4T

• Switch Type:

  SLIDE SWITCH

• Terminal Finish:

  Silver (Ag)

• Termination Type:

  SOLDER

• Washability:

  SOLVENT
