SM5S24AHE3_A/I - Vishay

SM5S24AHE3_A/I Details

• Manufacturer Part Number:

  SM5S24AHE3_A/I

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Factory Lead Time:

  7 Weeks

• Date Of Intro:

  2016-09-25

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  0

• Additional Feature:

  HIGH RELIABILITY, PD-CASE

• Breakdown Voltage-Max:

  29.5 V

• Breakdown Voltage-Min:

  26.7 V

• Case Connection:

  ANODE

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JEDEC-95 Code:

  DO-218AB

• JESD-30 Code:

  R-PSSO-C1

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Non-rep Peak Rev Power Dis-Max:

  3600 W

• Number of Elements:

  1

• Number of Terminals:

  1

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  245

• Polarity:

  UNIDIRECTIONAL

• Power Dissipation-Max:

  5 W

• Reference Standard:

  AEC-Q101

• Rep Pk Reverse Voltage-Max:

  24 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Finish:

  Matte Tin (Sn) - with Nickel (Ni) barrier

• Terminal Form:

  C BEND

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  30
