SMCG120A-E3/57T - Vishay

SMCG120A-E3/57T Details

• Manufacturer Part Number:

  SMCG120A-E3/57T

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SMCG, 2 PIN

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Factory Lead Time:

  5 Weeks

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  6.86

• Additional Feature:

  EXCELLENT CLAMPING CAPABILITY, UL RECOGNIZED

• Breakdown Voltage-Max:

  147 V

• Breakdown Voltage-Min:

  133 V

• Breakdown Voltage-Nom:

  140 V

• Clamping Voltage-Max:

  193 V

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JEDEC-95 Code:

  DO-215AB

• JESD-30 Code:

  R-PDSO-G2

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Non-rep Peak Rev Power Dis-Max:

  1500 W

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity:

  UNIDIRECTIONAL

• Power Dissipation-Max:

  6.5 W

• Qualification Status:

  Not Qualified

• Reference Standard:

  UL RECOGNIZED

• Rep Pk Reverse Voltage-Max:

  120 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30
