SMHV0550 - HVM TECH

SMHV0550 Details

• Manufacturer Part Number:

  SMHV0550

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• Package Description:

  PACAKGE-9

• ECCN Code:

  EAR99

• Manufacturer:

  HVM Technology

• Additional Feature:

  SEATED HEIGHT NOM

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Efficiency (Main Output):

  60%

• Input Voltage-Max:

  5.5 V

• Input Voltage-Min:

  4.5 V

• Input Voltage-Nom:

  5 V

• JESD-30 Code:

  S-PDMA-P9

• Length:

  21.59 mm

• Line Regulation-Max:

  0.01%

• Load Regulation-Max:

  0.2%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  0.0002 A

• Output Voltage-Max:

  5000 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Shape:

  SQUARE

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Seated Height-Max:

  15.24 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  1 W

• Trim/Adjustable Output:

  YES

• Width:

  21.59 mm
