SOS-1225-119+ - Mini-Circuits

SOS-1225-119+ Details

• Manufacturer Part Number:

  SOS-1225-119+

• Rohs Code:

  Yes

• Part Life Cycle Code:

  End Of Life

• ECCN Code:

  EAR99

• Manufacturer:

  Mini-Circuits

• YTEOL:

  0.4

• Control Voltage-Max:

  3 V

• Control Voltage-Min:

  0.5 V

• JESD-609 Code:

  e4

• Modulation Sensitivity:

  42 MHz/V

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  12

• Offset Frequency:

  1 kHz

• Operating Frequency-Max:

  1225 MHz

• Operating Frequency-Min:

  1185 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Oscillator Type:

  VOLTAGE CONTROLLED OSCILLATOR

• Output Power:

  -0.2 dBm

• Package Body Material:

  METAL

• Package Equivalence Code:

  LCC12/16,.3SQ,60

• Phase Noise:

  -79 dBc/Hz

• Physical Dimension:

  7.62mm x 7.62mm x 2.54mm

• Qualification Status:

  Not Qualified

• Supply Current-Max:

  14 mA

• Supply Voltage-Nom:

  3 V

• Surface Mount:

  YES

• Terminal Finish:

  GOLD OVER NICKEL
