SP1064E-04UTG - LITTELFUSE

SP1064E-04UTG Details

• Manufacturer Part Number:

  SP1064E-04UTG

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  7.11

• Additional Feature:

  IR-NOM

• Breakdown Voltage-Max:

  73 V

• Breakdown Voltage-Min:

  62 V

• Breakdown Voltage-Nom:

  68 V

• Case Connection:

  CATHODE

• Clamping Voltage-Max:

  102 V

• Configuration:

  COMMON ANODE, 5 ELEMENTS

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JEDEC-95 Code:

  MO-229

• JESD-30 Code:

  R-PDSO-N10

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Number of Elements:

  5

• Number of Terminals:

  10

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Polarity:

  UNIDIRECTIONAL

• Reference Standard:

  IEC-61000-4-2, 4-4, 4-5

• Rep Pk Reverse Voltage-Max:

  60 V

• Reverse Current-Max:

  0.05 µA

• Reverse Test Voltage:

  60 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  NO LEAD

• Terminal Position:

  DUAL
