SP2504NUTG - LITTELFUSE

SP2504NUTG Details

• Manufacturer Part Number:

  SP2504NUTG

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  7

• Additional Feature:

  LOW CAPACITANCE

• Breakdown Voltage-Max:

  5 V

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JEDEC-95 Code:

  MO-229

• JESD-30 Code:

  S-PDSO-N10

• Non-rep Peak Rev Power Dis-Max:

  300 W

• Number of Elements:

  1

• Number of Terminals:

  10

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity:

  UNIDIRECTIONAL

• Rep Pk Reverse Voltage-Max:

  2.5 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Form:

  NO LEAD

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  40
