SPA06B - LITTELFUSE

SPA06B Details

• Manufacturer Part Number:

  SPA06B

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  6

• Actuator Material:

  NYLON

• Actuator Type:

  SLIDE TYPE

• Additional Feature:

  ROHS COMPLIANT 25 PCS/TUBE

• Body Breadth:

  3.2 mm

• Body Height:

  6.2 mm

• Body Length or Diameter:

  18.84 mm

• Center Contact Material:

  BERYLLIUM COPPER

• Center Contact Plating:

  GOLD OVER NICKEL

• Contact Current(DC)-Max:

  0.0001 A

• Contact (DC) Max Rating R Load:

  .0001A@.0001VDC

• Contact Resistance:

  0.05 mΩ

• Contact Voltage(DC)-Max:

  0.0001 V

• Dielectric Withstand Volts:

  300VAC V

• Electrical Life:

  1000 Cycle(s)

• End Contact Material:

  COPPER ALLOY

• End Contact Plating:

  GOLD OVER NICKEL

• Housing Material:

  POLYBUTYLENE TEREPHTHALATE

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  POLYPHENYLENE SULPHIDE

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Switch Sections:

  6

• Operating Temperature-Max:

  60 °C

• Operating Temperature-Min:

  -30 °C

• PCB Hole Count:

  8

• Packing Method:

  TUBE

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPST

• Switch Type:

  PIANO DIP SWITCH

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier

• Terminal Length:

  0.141 inch

• Termination Type:

  SOLDER
