SQJ500AEP-T1_GE3 - Vishay

SQJ500AEP-T1_GE3 Details

• Manufacturer Part Number:

  SQJ500AEP-T1_GE3

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SO-8L, 4 PIN

• Country Of Origin:

  Germany

• ECCN Code:

  EAR99

• Factory Lead Time:

  20 Weeks

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  6

• Avalanche Energy Rating (Eas):

  35 mJ

• Case Connection:

  DRAIN

• Configuration:

  SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  40 V

• Drain Current-Max (ID):

  30 A

• Drain-source On Resistance-Max:

  0.0092 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  111 pF

• JESD-30 Code:

  R-PSSO-G4

• Number of Elements:

  2

• Number of Terminals:

  4

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity/Channel Type:

  N-CHANNEL AND P-CHANNEL

• Pulsed Drain Current-Max (IDM):

  120 A

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Transistor Element Material:

  SILICON

• Turn-off Time-Max (toff):

  49 ns

• Turn-on Time-Max (ton):

  30 ns
