SQM10AJB-0R47 - Yageo Group

SQM10AJB-0R47 Details

• Manufacturer Part Number:

  SQM10AJB-0R47

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Mainland China, Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8533.21.00.80

• Manufacturer:

  YAGEO Corporation

• YTEOL:

  10

• Additional Feature:

  FLAME PROOF

• Construction:

  Rectangular

• JESD-609 Code:

  e3

• Lead Diameter:

  0.8 mm

• Lead Length:

  3.5 mm

• Lead Spacing:

  5 mm

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Terminals:

  2

• Operating Temperature-Max:

  275 °C

• Operating Temperature-Min:

  -55 °C

• Package Height:

  51 mm

• Package Length:

  13 mm

• Package Shape:

  RECTANGULAR PACKAGE

• Package Style:

  Radial

• Package Width:

  9 mm

• Packing Method:

  BULK

• Rated Power Dissipation (P):

  10 W

• Rated Temperature:

  40 °C

• Resistance:

  0.47 Ω

• Resistor Type:

  FIXED RESISTOR

• Surface Mount:

  NO

• Technology:

  WIRE WOUND

• Temperature Coefficient:

  300 ppm/°C

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Shape:

  WIRE

• Tolerance:

  5%

• Working Voltage:

  500 V
