SS-42D28-GNS - LITTELFUSE

SS-42D28-GNS Details

• Manufacturer Part Number:

  SS-42D28-GNS

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Vietnam

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  7

• Actuator Material:

  POLYOXYMETHYLENE

• Actuator Type:

  SLIDE

• Body Breadth:

  7.0104 mm

• Body Height:

  8.509 mm

• Body Length or Diameter:

  16.51 mm

• Center Contact Plating:

  SILVER

• Contact Current(DC)-Max:

  0.3 A

• Contact (DC) Max Rating R Load:

  0.3A@30VDC

• Contact Resistance:

  0.03 mΩ

• Contact Timing:

  BREAK-BEFORE-MAKE

• Contact Voltage(DC)-Max:

  30 V

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  10000 Cycle(s)

• End Contact Plating:

  SILVER

• Insulation Resistance:

  100000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Positions:

  2

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• PCB Hole Count:

  14

• Surface Mount:

  NO

• Switch Function:

  4PDT

• Switch Type:

  SLIDE SWITCH

• Terminal Length:

  0.118 inch

• Termination Type:

  SOLDER
