SSM015L2HN - TE Connectivity

SSM015L2HN Details

• Manufacturer Part Number:

  SSM015L2HN

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Body Depth:

  0.086 inch

• Body Length:

  0.559 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  D NANOMINIATURE CONNECTOR

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Gender:

  FEMALE

• Contact Material:

  NOT APPLICABLE

• DIN Conformance:

  NO

• EMI Shielded:

  NO

• Empty Shell:

  YES

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insulator Color:

  NATURAL

• Insulator Material:

  LIQUID CRYSTAL POLYMER

• MIL Conformance:

  NO

• Mains Connector Rating:

  115/230VAC

• Mixed Contacts:

  NO

• Mounting Option 2:

  JACKSCREW

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Ports:

  1

• Number of Rows Loaded:

  1

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Plating Thickness:

  90u inch

• Polarization Key:

  POLARIZED

• Shell Finish:

  NICKEL

• Terminal Pitch:

  0.64 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  15
